Product Description
1. PLC control system with touch panel operation
2. Full-automatic four-shaft exchange is adopted and the efficiency is improved.
3.The unwinding tension is adopted with powder brake control.
4. The banana roller is used to eliminate tape wrinkles during extension and feeding.
5. Unwind double-press roller can reduce noise.
6. (Optional) Auto tabbing device, jumbo roll up-lifter, noise hood and air score knives for
masking tape converting.
7.Spool trim winder is used for edge trimming collect and if tape gets broken during running, machine will auto stop.
Main Technical Parameters:
| Model | GL213 -1300mm | GL213 -1600mm |
| Effective width | 1320mm | 1620mm |
| Max. unwind diameter | 800mm | 800mm |
| Min. slitting width | 10mm | 10mm |
| Max. rewind diameter(shaft3″) exchange 4 shafts | 180mm | 180mm |
| Max. rewind diameter(shaft3″) exchange 2 shafts | 300mm | 300mm |
| Machine speed | 0-180m/min | 0-180m/min |
| slitting blade | 0.2×22×60mm | 0.2×22×60mm |
| Main power | 4kw | 4kw |
